M3 Mobility Scooter Operating Manual

CATALOGUE

Ⅰ. Safety Operation........4

Ⅱ. Instructions........7

III. Folding and unfolding.....11

IV. Charging and maintenance of battery .......12

Ⅴ.Maintenance and Care......13

Ⅵ.SAFETY........14

Ⅶ.WARRANTY ........... 19

Ⅷ.PARTS ORDER INFORMATION ........ 20

Ⅸ. PERFPRMANCE PARAMETER ....... 20

Ⅹ.COMMON FAULT AND ELIMINATING METHODS ...... 21

I. Safety Operation

To ensure a safe, comfortable, and smooth driving experience, please read this section thoroughly before your first ride. Your safety is our priority. If you have any questions, please reach out to your local dealer for assistance.

I. Pre-Operation Checklist

Know Your Local Traffic Rules This scooter is categorized as a non-motorized vehicle. While a driver’s license is not required, you must follow the same traffic regulations as pedestrians. Always use crosswalks or non-motorized lanes. When traveling along roadsides, avoid crossing diagonally or making sudden movements into traffic.

Practice Before You Ride Before your first trip, take time to familiarize yourself with all controls. Find a quiet, safe area with flat ground to practice accelerating, braking, reversing, turning, and handling inclines. Do not venture onto busy roads until you are fully confident in your steering.

Vehicle Inspection Before every use, ensure the brakes are responsive, all electronic functions are working correctly, and the battery is fully charged.

⚠️ WARNING:

Moisture Protection: Never expose the electrical system to rain, snow, or damp conditions for long periods. Do not wash the scooter with a direct water hose. If the scooter gets wet, ensure it is completely dry and functional before restarting.

Environmental Hazards: Avoid driving in extreme weather (heavy rain, fog, strong winds) or on difficult terrain like sand, mud, or ice to prevent accidents.

Physical Condition: Never operate the scooter under the influence of alcohol, while fatigued, or if you have a medical condition that could lead to a sudden loss of physical control.

2. Safe Driving Guidelines

Single Rider Only: This scooter is strictly for one person. Do not carry passengers or use the vehicle to tow cargo.

Stay Seated: Always remain seated while driving and keep a firm grip on the handlebars. Avoid aggressive steering ("serpentine" driving) or sharp turns at high speeds, as this may cause the scooter to tip.

Stay Focused: Reduce speed in congested areas or on uneven roads. Never use a mobile phone or wireless device while moving. If you must take a call, stop in a safe spot and turn off the power first.

Reversing & Elevators: Always check your surroundings before reversing. Move slowly when entering or exiting rooms and elevators. Never use your scooter on an escalator.

Inclines & Obstacles: Approach slopes straight-on at a low speed. Do not attempt to climb hills that exceed the scooter’s rated limit. Avoid driving over obstacles or curbs higher than 8 cm (approx. 3 inches).

Intersections: Always obey traffic lights. Stop and look both ways before proceeding slowly when the light turns green.

System Care: Avoid repeatedly switching the power lock on and off or making frequent "jackrabbit" starts and stops.

Authorized Use Only: Do not lend your scooter to anyone unfamiliar with its operation, and never allow children to play with the controls.

3. Post-Operation Care

Secure Parking: When leaving the scooter, always turn off the power and take the key with you.

Long-term Storage: If you do not plan to use your scooter for more than one week, please disconnect the battery to preserve its lifespan.

Ⅱ. Instructions

(1）Display Function Instructions:

Please see the follow picture:



1.Ignition

Powers the scooter's electrical system on and off.

2. Throttle Control Levers

 Manages forward and reverse movement, speed adjustment, and braking.

To Move Forward: After turning the key, use your right hand to pull the right lever toward you. The further you pull the lever, the faster the scooter travels.

To Reverse: Use your left hand to pull the left lever toward you.

To Stop: Gradually release the lever to slow down. Once the lever returns to its center (neutral) position, the electronic brake will engage automatically, bringing the scooter to a complete stop.

3. Speed Control Knob Sets the maximum speed limit for your ride.

Turn clockwise (toward the hare) to increase the top speed.

Turn counter-clockwise (toward the turtle) to lower the speed for safer maneuvering in tight spaces.

4. Headlight Switch Press once to illuminate the front LED headlights for night riding. Press again to turn them off.

5. Horn Button Press this button to sound the alert and warn pedestrians or other vehicles of your presence.

6. Digital Display Panel Once powered on, the screen provides real-time data including:

Battery Gauge: Shows remaining power. A full bar indicates a high charge. If the bar drops to half or below, please charge the battery promptly to avoid getting stranded.

Speedometer: Displays your current traveling speed.

Odometer: Tracks the total mileage the scooter has traveled.

Other functions and introduction:

1.Brake Mode Switch (Electric vs. Manual)

This switch controls the clutch to toggle between "Electric Driving" and "Manual Push" modes.

Electric Driving Mode: When the switch is set to the "Electric" position, the automatic brake is engaged. The scooter cannot be pushed by hand, but it can be driven normally using the battery power.

Manual Push Mode: When the switch is set to the "Manual" position, the brake is released, allowing the scooter to be pushed manually.

Note: This mode is only available when the power is on and the system is in standby. The motor will not drive the wheels in this mode.

⚠️ SAFETY WARNING: Never switch to "Manual" mode while on a downhill slope. The automatic brake will not function, which may lead to a loss of control. Always keep the switch in "Electric" mode when on an incline.

2.Charging the Battery

Always turn off the scooter's power before charging.

1.Plug the charger's output connector into the scooter's charging port or directly into the battery box.

2.Plug the input end into a standard household wall outlet and turn on the charger.

3.Indicator Lights: The light stays Red while charging and turns Green once fully charged.

Note: Only use the specialized charger provided with your scooter to avoid damaging the battery.

3. Fuse & Overload Protection

Fuse: If the power is on but the display screen remains blank, please inspect the fuse for any abnormalities.

Overload Protector: If the load is too heavy or the incline is too steep, the protector on the battery box may trigger to cut off power for safety. To restore power, simply press the overload protector button again.

4. Removable Battery Compartment

The battery compartment is designed for convenience. Simply pull the carrying handle vertically upward to remove it. This allows you to charge the batteries separately from the scooter.

How to Drive Your Scooter

Start-Up: Sit comfortably on the seat, then insert the key or trigger the electric lock to turn on the power.

Moving Forward: Hold the handlebars with both hands. Use your right-hand fingers to slowly pull the toggle (lever) toward you to begin moving.

Adjusting Speed: Use the speed knob to find a comfortable pace based on your surroundings and personal preference.

Stopping: To stop, simply release the toggle. It will automatically return to the center position, engaging the brakes for a smooth, safe stop.

Reversing: To back up, check your surroundings first. Use your left-hand fingers to slowly pull the left toggle. Release the toggle to stop smoothly.

III. Folding and unfolding

·Manual folding and unfolding



Designed with convenience in mind, the M3 can be lifted in a mere three seconds. Just hold it by the designated spot shown in the box, and you'll find it surprisingly easy to carry.

IV. Charging and maintenance of battery

·electric scooter battery maintenance common sense

The lifespan of a battery is not only related to the quality of the product from the manufacturer and the system configuration of the electric mobility scooter, but it also has a lot to do with how the consumer uses and maintains it. Therefore, while demanding quality from the manufacturer, it is also extremely important to understand and master the knowledge of battery maintenance.

1. "Saturated State": Develop the habit of keeping the battery fully charged. Whether you ride 5 miles or 10 miles each day, you should recharge the battery to keep it in a "saturated state" over the long term.

2. Regular Deep Discharge: It is recommended to perform a deep discharge once every two months. Do not store the battery in a discharged state, as this can severely affect its lifespan. The longer it is left idle, the more damage it will sustain.

3. Avoid High Current Discharge: High current discharge can harm the battery, so overloading is not recommended. Temperature greatly affects the battery's capacity,  so the charging time  should be appropriately extended when the temperature is low.

4. Maintain the Scooter and Battery: Ensure that other parts of the scooter are in good condition and keep the battery surface clean. Avoid long-term exposure to sunlight, especially while charging. It is best to store the scooter in a cool, ventilated, and dry place.

Ⅴ.Maintenance and Care

In order to maintain good performance of the scooter, reduce the occurrence of failures,Make your driving safe and comfortable.In daily use, please pay attention to the following points：

1. Read the safety instructions carefully, fully understand the meanings.The electric scooter controller is the key component of the scooter,Don't open it yourself or Manipulate other configurations to change controller’s performance.The controller surface should always be wiped with a dry, soft cloth,It is forbidden to use the controller in the environment of excessive temperature, overload, and excessive humidity.

2. Do not attempt to open, repair, or modify the internal structure of the motor, as this may damage the motor and void the warranty.It is strictly prohibited to overload and block for a long time, and the dirt on the surface of the motor should be cleaned frequently, especially the dirt on the cable of the motor.It is strictly prohibited to allow water to enter. Crossing water puddles deeper than 5 cm may cause water to enter the motor, potentially resulting in permanent damage to the motor.

3. Do not use gasoline or other chemicals to wipe the electric mobility scooter ’s casing or other parts. Use a soft cloth that has been dampened and wrung out. Additionally, regularly inspect and maintain the electric mobility scooter.

Check daily to see if the battery needs charging, and inspect the brakes before driving to ensure they are functioning correctly. Regularly check if the lever's fixing screws are loose and ensure the lever is in a neutral position. Avoid getting the electrical system wet, and use the scooter only after it has dried. Periodically check the battery status and clean the battery terminals if necessary. If the scooter is not used for a long period, charge it approximately once a month. Regularly inspect the insulation of the wires and ensure all connectors are making good contact. Check if the front and rear tires are wobbling.

Ⅵ.SAFETY

1. PRE-RIDE SAFETY CHECK

Check all electrical connections. Make sure they are tight and not corroded.

Check all connections to the battery box. Make sure they are secured properly.

Check the brakes. Make sure they are sensitive and reliable.

Check the battery charge.

2. WEIGHT LIMITATIONS

Your scooter is limited to a 330LBS (150KG) maximum weight limit.



3.INCLINE INFORMATION



The maximum safe slope of an incline is of 15 °for your scooter. If a slope is less than this angle, it is safety for your scooter whenever climb or descent.

4. OUTDOOR DRIVING SURFACES

You scooter is designed to provide optimum stability under normal driving conditions-dry, level surfaces composed of concrete,blacktop,asphalt, or hard dirt. But you should avoid driving on the following roads:

Surface that you feel unsure about or soft pavement.

Tall grass that can become tangled in the running gear.

Loosely packed gravel and sand beach.

The max height of curb is 3. 15IN(8cm).

5. MANUAL FREEWHEEL MODE

Your scooter is equipped with a manual freewheel lever that allows the scooter to be manually pushed by your attendant. For more information,see V “Operation ”.



6.ELECTROMAGNETIC INTERFERENCE

u Electrical devices may be affected by Electromagnetic Interference(EMI) or Radio Frequency Interference (RFI) that are produced by radio waves from radio stations,TV stations and other radio transmitters. Like any electrical devices, your scooter may be affected by EMI/RFI. Especially, when your scooter is driven in the interference influence range of these radio transmitters. In this case your scooter may be out of order due to their interference.

7. TRANSFER ONTO OR OFF SCOOTER

To avoid an injury, the following safety precautions are useful for you while you attempt to transfer on or off your scooter.

Remove the key from the key switch, see V. OPERATION.

Ensure your scooter is not in manual freewheel mode.

Flip up or move away the armrests.

Reduce the distance between you and your scooter or an object you are transferring onto.

Turn the front wheels forward to improve your scooter's stability during transfer.



8. Inclement Weather Precautions





Ⅶ.WARRANTY

All of design and production processes of ECOMOBI products are managed in accordance with ISO 9001 to guarantee their

quality.Warranty service will be performed by the authorized ECOMOBI provider incooperation with the ECOMOBI after-service department.

WARRANTY INCLUDING

1.One-year warranty on the front and the rear main frames from the date of purchase.

2.One-year warranty on the following parts from the date of purchase from the date of purchase:

♢Electric control system and the controller.

♢Motor/gearbox assembly.

♢Charger.

3. Six-month limited warranty on batteries from the date of purchase.

OUT OF THE WARRANTY

♢ABS Shroud worn out.

♢Tires.

♢Upholstery and seat.

♢Damage caused due to abuse miss operation, accident and negligence.

♢Damage caused due to improper operation, maintenance and storage.

♢ Business or other non-normal use.

IMPORTANT NOTICE!

The maximum speed and maximum range indicated for this product were measured

under ideal laboratory conditions with a test rider weighing 165LBS. In actual use, the maximum speed and range may be affected by various factors, including but not

limited to:

User's weight: Heavier users may experience reduced speed.

Road conditions: Slopes, uneven, or rough surfaces can affect the vehicle's speed. Battery condition: Low battery charge or aged batteries may result in decreased speed.

Tire condition: Worn tires can increase rolling resistance, impacting speed.

Ambient temperature: Extreme heat or cold can affect battery and motor performance, thereby influencing speed.

Driving habits: Aggressive acceleration, sudden braking, and other driving behaviors can affect energy consumption and speed.

Therefore, the performance of the mobility scooter in real-world conditions may differ from the laboratory test results. Users are advised to be aware of this and adjust their usage accordingly based on actual conditions.

Ⅸ.PARTS ORDER INFORMATION

Original Idea: If you need spare parts, contact Ecomobi via Amazon or our website. Refined English: > "Should you require replacement parts for your scooter, please reach out to the Ecomobi Service Team. You can contact us directly through our Amazon store or visit our official brand website at ecomobiclub.com for assistance."
