Introduction
Thank you for purchasing our company's electric mobility scooter series products. Electric mobility scooters are designed specifically for the elderly and individuals with limited mobility. They primarily serve the elderly and those with mobility challenges. Additionally, they can be used as commuting vehicles for large company managers, security patrols, and as transportation or shopping tools in golf courses, large theme parks, amusement parks, zoos, museums, sightseeing communities, and large supermarkets. Before using the electric mobility scooter, please read this user manual carefully and thoroughly, as it is crucial for your safe operation. Also, if you transfer this scooter to another person, please ensure that the manual is given to the new owner as well.
II. Safety Operation
Before using the electric mobility scooter for the first time, please read this section carefully and understand all precautions to ensure safe, comfortable, and free driving of the scooter. This is very important for you. If you have any questions, please contact your dealer
Before Operation:
1.Familiarize Yourself with Local Traffic Regulations
The electric mobility scooter is classified as a non-motor vehicle. According to traffic laws, a driver's license is not required, but you must obey traffic regulations just like pedestrians. Please use pedestrian crossings or non-motorized lanes. When driving along the roadside, do not suddenly cross the road diagonally.
2.Practice Operation
Before operating the electric mobility scooter for the first time, familiarize yourself with its various functions. Practice moving forward, accelerating, decelerating, stopping, reversing, climbing, descending, and turning in a place with few people, good ground conditions, and safe surroundings. Only take it on the road once you have mastered these operations. Before your first use, check the condition of the scooter, ensuring the brakes are responsive, all functions are normal, and the battery is adequately charged
Warning:
Never expose the electrical system of your electric mobility scooter to damp environments for extended periods (e.g., rain, snow).
Do not wash the scooter body directly with water. If it gets wet, ensure it is dry and fault-free before use.
Do not operate the scooter in adverse weather conditions such as rain, snow, fog, strong winds, or extreme temperatures. Avoid driving in deserts, beaches, muddy areas, or on wet, icy, or slippery surfaces to prevent performance issues and accidents.
Do not operate the scooter under the influence of alcohol, when overly fatigued, or in a state of confusion. If the operator has a mental illness or any condition that might cause sudden loss of control, do not drive the scooter.
During Operation:
1. This electric mobility scooter is limited to one person. Do not carry passengers. The scooter should not be used for transporting or towing
goods.
2. Do not stand while driving the scooter. The operator must sit on the seat and hold the handlebars firmly. Avoid serpentine driving, sharp turns at high speeds, and shifting your body to prevent tipping.
3. Pay close attention and reduce speed when driving on uneven or complex roads and in congested areas. Do not use mobile phones or other 5wireless communication devices while driving. Stop the scooter in a safe
place and turn off the power before using such devices.
4.When reversing, pay attention to the surroundings and move slowly. When exiting rooms or elevators, move slowly and do not use escalators
for going up or down.
5.When climbing or descending slopes, stay highly attentive, grip the handlebars firmly, and proceed straight at low speed. Do not forcefully climb slopes that exceed the scooter's limit. Avoid crossing obstacles or steps higher than 8 cm, as this may impede the scooter's movement.
6.When driving through an intersection, please obey traffic rules, do not run a red light, stop and observe first, and then drive slowly when the light turns green.
7. Do not intentionally open or close the electric door lock frequently, and do not start or stop the electric scooter frequently.
8. Do not lend the electric scooter to people who have never used or are not familiar with the electric scooter for use and operation, and do not let children play with the switch and the operating handle.
After operation:
1. After parking, please turn off the electric door lock when no one is there, and do not leave the key on the electric door lock.
2. If you do not use the electric scooter for more than 1 week, please disconnect the battery.
II.Instructions
（1）Display Function Instructions
Please see the follow picture:
1. Electric lock
Control the power on and off of the scooter.
2.DrivingLeverÿ
Control the scooter's forward, reverse, acceleration, deceleration, and parking. After turning on the electric door lock, Use your right hand to pull the lever backward on the right side of the instrument, and the scooter will move forward. The greater the angle, the faster the speed. Slowly release the lever and the scooter will decelerate. When it is fully released and the lever is reset, the scooter will stop and be in the braking state. Similarly, use your left finger to pull the lever backwards on the left side of the instrument, and the scooter will move backwards. The greater the angle, the faster the speed. Slowly release the lever and the scooter will decelerate. When it is fully released and the lever is reset, the scooter will stop and be in the braking state.
3. Speed adjustment knob
Adjust the maximum speed of the scooter. Turn clockwise to increase the speed gradually, and turn counter-clockwise to decrease the speed gradually.
4.Headlight button
Press this button to turn on the headlights, and press it again to turn off the headlights.
5.Horn
Press this button to sound the horn.
6.Display
Turn on the power switch, the screen will show the battery power, driving speed, total mileage. A full bar means the power is strong, a half bar means the power is very low and the battery must be charged in time.
![]()
Notice: Switch button for brake
Control clutch and release of brake could switch to“electric driving” and “manual driving”.
“Electric driving": When the brake button is switched to the ‘electric’ position, the scooter is in the braking state,cannot be pushed, at this time the scooter can be electric driven normally.
“Manual driving": When the brake button is switched to the ‘manual’ position, the scooter is in the state of brake release, and the scooter can be pushed. (Notice: This function can only be activated when the power is on and the system is in standby mode. The scooter cannot be driven during this time)
When going downhill, do not switch the brake lever to the "manual" position, entering the "Manual driving" mode, as there will be no braking effect at this time. This is to ensure the safety of the user and the mobility scooter.
Charging port
Please turn off the scooter power switch firstly, then charge.
Insert the plug of the output end of the charger into the charging socket of the electric mobility scooter or the charging socket on the battery, and then insert the plug of the input end into the household power supply, and then turn on the switch of the charger. When the charger is charging, the indicator light is red, and the red indicator light changes to green when fully charged. Please use the special charger for this scooter, otherwise the battery may be damaged.
Fuse and overload protector
When the power is turned on and there is no indication on the power indicator meter, please check whether the fuse is abnormal or not.
When the load is too heavy or the climb is too steep, the overload protector on the battery box will activate the self-protection and cut off the power supply automatically; press the overload protector again and the power supply will be restored.
Removable battery compartment
Pull on the carrying handle and pull vertically upwards to remove the battery compartment, the batteries can be charged separately.
(2)How to drive the scooter
When the driver gets into the scooter and sits down, trigger the electric door lock key and turn on the power.
Hold the handle with both hands and slowly move the toggle forward with the fingers of your right hand to move the scooter forward.
Adjust the speed adjusting knob according to the road condition, surrounding condition and personal preference to adjust the traveling speed.
When you want to stop the scooter, simply release the toggle with your right hand to return it to the center position for a smooth stop.
When backing up, pay attention to the surrounding conditions, use the fingers of the left hand to move forward slowly toggle can be, when parking to release the toggle, the scooter can be smoothly parked.
Note:When the operating lever is pressed downward, the scooter enters electric driving mode and can be used normally.
When the operating lever is pulled upward, the scooter is locked and cannot be driven.
Ⅲ. Fully automatic folding
“- ” Button Controls the scooter to unfold
“= ” Button Controls the scooter to fold/retract
“O ” Position Enables the remote control folding function
Remote Control “A” Button Controls the scooter to unfold
Remote Control “B” Button Controls the scooter to fold/retract
Steps:
Remove the battery and connection cable from the package.
Connect the battery to the scooter to power it on.
Press the automatic folding button downward to the “= ” position, the scooter will unfold automatically.
After unfolding, place the battery into the pedal battery compartment to complete battery installation.
Switch the automatic folding button to the “O” position to enable remote control folding.
Cautions :
The remote control has a current protection function. After using the remote to fold the scooter twice consecutively, you may experience a “pause” effect. In this case, use the on-board automatic folding button to fold the scooter.
Ensure sufficient space before using the unfolding function to avoid collision.
Avoid using the function repeatedly within a short period to prevent overheating of the motor.
Ensure there is at least 1 meter (3 feet) of clearance in front and behind the scooter before unfolding.
Do not stand or place objects on the scooter while it is folding or unfolding.
Contact customer service if abnormal noises, jerking, or incomplete folding persist.
IV. Charging and maintenance of battery
electric scooter battery maintenance common sense
The lifespan of a battery is not only related to the quality of the product from the manufacturer and the system configuration of the electric mobility scooter, but it also has a lot to do with how the consumer uses and maintains it. Therefore, while demanding quality from the manufacturer, it is extremely important to understand and master the knowledge of battery maintenance.
"Saturated State": Develop the habit of keeping the battery fully charged. Whether you ride 5 miles or 10 miles each day, you should recharge the battery to keep it in a "saturated state" over the long term.
Regular Deep Discharge: It is recommended to perform a deep discharge once every two months. Do not store the battery in a discharged state, as this can severely affect its lifespan. The longer it is left idle, the more damage it will sustain.
Avoid High Current Discharge: High current discharge can harm the battery, so overloading is not recommended. Temperature greatly affects the battery's capacity, so the charging time should be appropriately extended when the temperature is low.
Maintain the Scooter and Battery: Ensure that other parts of the scooter are in good condition and keep the battery surface clean. Avoid long-term exposure to sunlight, especially while charging. It is best to store the scooter in a cool, ventilated, and dry place.
Ⅴ.Maintenance and Care
In order to maintain good performance of the scooter, reduce the occurrence of failures,Make your driving safe and comfortable.In daily use, please pay attention to the following points:
Read the safety instructions carefully,fully understand the meanings.The electric scooter controller is the key component of the scooter,Don't open it yourself or Manipulate other configurations to change controller’s performance.The controller surface should always be wiped with a dry, soft cloth,It is forbidden to use the controller in the environment of excessive temperature, overload, and excessive humidity.
Do not attempt to open, repair, or modify the internal structure of the motor, as this may damage the motor and void the warranty.It is strictly prohibited to overload and block for a long time, and the dirt on the surface of the motor should be cleaned frequently, especially the dirt on the cable of the motor.It is strictly prohibited to allow water to enter. Crossing water puddles deeper than 5 cm may cause water to enter the motor, potentially resulting in permanent damage to the motor.
Do not use gasoline or other chemicals to wipe the electric mobility scooter’s casing or other parts. Use a soft cloth that has been dampened and wrung out. Additionally, regularly inspect and maintain the electric mobility scooter.
Check daily to see if the battery needs charging, and inspect the brakes before driving to ensure they are functioning correctly. Regularly check if the lever's fixing screws are loose and ensure the lever is in a neutral position. Avoid getting the electrical system wet, and use the scooter only after it has dried. Periodically check the battery status and clean the battery terminals if necessary. If the scooter is not used for a long period, charge it approximately once a month. Regularly inspect the insulation of the wires and ensure all connectors are making good contact. Check if the front and rear tires are wobbling.
Ⅵ.SAFETY
1. PRE-RIDE SAFETY CHECK
Check all electrical connections. Make sure they are tight and not
corroded.
Check all connections to the battery box. Make sure they are secured
properly.
Check the brakes. Make sure they are sensitive and reliable.
Check the battery charge.
2. WEIGHT LIMITATIONS
Your scooter is limited to a 330LBS (150KG) maximum weight limit
3.INCLINE INFORMATION
The maximum safe slope of an incline is of 15°for your scooter. If a slope is less than this angle, it is safety for your scooter whenever climb or descent.
4. OUTDOOR DRIVING SURFACES
You scooter is designed to provide optimum stability under normal
15driving conditions-dry, level surfaces composed of concrete,
blacktop,asphalt, or hard dirt. But you should avoid driving on the
following roads:
Surface that you feel unsure about or soft pavement.
Tall grass that can become tangled in the running gear.
Loosely packed gravel and sand beach.
The max height of curb is 3.15IN(8cm).
5. MANUAL FREEWHEEL MODE
Your scooter is equipped with a manual freewheel lever that allows
the scooter to be manually pushed by your attendant. For more
information,see V “Operation”.
6.ELECTROMAGNETIC INTERFERENCE
Electrical devices may be affected by Electromagnetic Interference (EMI) or Radio Frequency Interference (RFI) that are produced by radio waves from radio stations,TV stations and other radio transmitters. Like any electrical devices, your scooter may be affected by EMI/RFI. Especially, when your scooter is driven in the interference influence range of these radio transmitters. In this case your scooter may be out of order due to their interference.
7. TRANSFER ONTO OR OFF SCOOTER
To avoid an injury, the following safety precautions are useful for you
while you attempt to transfer on or off your scooter.
Remove the key from the key switch, see V. OPERATION.
Ensure your scooter is not in manual freewheel mode.
Flip up or move away the armrests.
Reduce the distance between you and your scooter or an object you
are transferring onto.
Turn the front wheels forward to improve your scooter's stability
during transfer.
8. Inclement Weather Precautions
Ⅶ.WARRANTY
All of design and production processes of ECOMOBI products are
managed in accordance with ISO 9001 to guarantee their
quality.Warranty service will be performed by the authorized ECOMOBI
provider incooperation with the ECOMOBI after-service department.
WARRANTY INCLUDING
1.One-year warranty on the front and the rear main frames from the date
of purchase.
2.One-year warranty on the following parts from the date of purchase
from the date of purchase:
Electric control system and the controller.
Motor/gearbox assembly.
Charger.
3. Six-month limited warranty on batteries from the date of purchase.
OUT OF THE WARRANTY
ABS Shroud worn out.
Tires.
Upholstery and seat.
Damage caused due to abuse miss operation, accident and negligence.
Damage caused due to improper operation, maintenance and storage.
Business or other non-normal use
Ⅷ. PERFPRMANCE PARAMETER
IMPORTANT NOTICE!
The maximum speed and maximum range indicated for this product were measured
under ideal laboratory conditions with a test rider weighing 165LBS. In actual use, the
maximum speed and range may be affected by various factors, including but not
limited to:
User's weight: Heavier users may experience reduced speed.
Road conditions: Slopes, uneven, or rough surfaces can affect the vehicle's speed.
Battery condition: Low battery charge or aged batteries may result in decreased
speed.
Tire condition: Worn tires can increase rolling resistance, impacting speed.
Ambient temperature: Extreme heat or cold can affect battery and motor
performance, thereby influencing speed.
Driving habits: Aggressive acceleration, sudden braking, and other driving
behaviors can affect energy consumption and speed.
Therefore, the performance of the mobility scooter in real-world conditions may differ
from the laboratory test results. Users are advised to be aware of this and adjust their
usage accordingly based on actual conditions.
Ⅸ.PARTS ORDER INFORMATION
If you need change the spare parts of scooter, please contact Ecomobi Service Team via Amazon or ecomobi brand website: ecomobiclub.com21
Ⅹ.COMMON FAULT AND
ELIMINATING METHODS
